Switching Valve

  • The automatic flanging machine produced by our company is an automated production equipment integrating functions such as heating, flanging, and cooling and shaping, specifically designed for flanging pipes. This equipment adopts advanced automatic control technology and can efficiently and accurately complete the flanging work of pipes, improving production efficiency and reducing labor costs. It is an important device in the modern plastic pipe processing industry.
Consult
Hotline+86 0512-57420512

Detailed introduction






Stator formInclined plane type
Port specification1/4-28UNF thread, compatible with hard pipe connection systems10-32UNF thread
Number of ports6-way, 8-way, 10-way12-channel, 16-channel24-channel, 32-channel
Path1.5 mm1.2mm0.5mm
Dead volume (port-to-port volume)4.5ul
Work pressureAir pressure: 0.8 MPa, water pressure: 1.6 MPa
Applicable mediumAll kinds of highly corrosive chemical media
Ambient temperature0~60℃
Medium temperature0~100℃
Relative humidity of the environment<80%
Leakage rate
The movement speed between ports≤4S/Circle
Maximum driving force6N/m
Voltage /DC24V
Current2A
Power48W
Communication rateRS-232/RS-4859600bps(Modifiable)
Valve body materialPCTFE、PEEK(Can be customized according to customer requirements)
Valve core materialCeramics, sapphire(Customization is available according to customer requirements)
